Note : Due to increasingly high demand, all bicycle sales are subject to vary in shipping/delivery times.
KEY PERFORMANCE FACTORS
Comfort
Liv’s 3F Design Philosophy and LivRight Sizing, along with the lightweight ALUXX-Grade Aluminum frame, create a flawlessly tuned and comfortable ride for women.
Confidence Inspiring
Flat bars, front suspension, and a low standover height provide generous stability and capable comfort.
Versatile
Perfect for fitness, commuting and exploration needs alike.
ALUXX ALUMINUM TECHNOLOGY
This Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.
Sizes: XS, S, M, L
Colors: Eclipse
Frame: ALUXX-Grade Aluminum
Fork: SR Suntour NEX HLO 700C, 63mm, disc
Shock: N/A
Handlebar: Giant Sport XC, 31.8
Stem: Giant Sport
Seatpost: Giant D-Fuse, alloy
Saddle: Liv Sport Comfort
Pedals: platform
Shifters: Shimano Deore
Front Derailleur: N/A
Rear Derailleur: Shimano Deore
Brakes: Tektro HD-M276, hydraulic disc
Brake Levers: Tektro
Cassette: Shimano CS-M4100, 11x46
Chain: KMC X10 with Missing Link
Crankset: ProWheel Charm, 40t
Bottom Bracket: sealed cartridge
Rims: Giant GX Disc
Hubs: alloy, 28h
Spokes: stainless, 14g
Tires: Giant CrossCut, 700x42c, puncture protect
Weight: The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
-
- XS : 4’10” - 5’4”
-
- S : 5’2” - 5’7”
-
- M: 5’5” - 5’9”
-
- L : 5’7” - 6’0”
| XS | S | M | L | ||
|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH (inch) | 15 | 16.5 | 18.1 | 19.7 |
| B | SEAT TUBE ANGLE | 74.0° | 73.5° | 73.0° | 73.0° |
| C | TOP TUBE LENGTH (inch) | 21.7 | 22.4 | 23.2 | 24 |
| D | HEAD TUBE LENGTH (inch) | 4.3 | 4.7 | 5.3 | 5.9 |
| E | HEAD TUBE ANGLE | 70.5° | 70.5° | 70.5° | 70.5° |
| F | FORK RAKE (inch) | 1.7 | 1.7 | 1.7 | 1.7 |
| G | TRAIL (inch) | 3.3 | 3.3 | 3.3 | 3.3 |
| H | WHEELBASE (inch) | 41.7 | 42.3 | 42.9 | 43.7 |
| I | CHAIN STAY LENGTH (inch) | 17.7 | 17.7 | 17.7 | 17.7 |
| J | BOTTOM BRACKET DROP (inch) | 2.4 | 2.4 | 2.4 | 2.4 |
| K | STACK (inch) | 23.7 | 24.1 | 24.6 | 25.2 |
| L | REACH (inch) | 14.9 | 15.3 | 15.7 | 16.3 |
| M | STAND OVER HEIGHT (inch) | 23.2 | 23.9 | 24.4 | 24.8 |
| N | HANDLEBAR WIDTH (inch) | 25.2 | 25.2 | 26.8 | 26.8 |
| O | STEM LENGTH (inch) | 2.8 | 3.1 | 3.1 | 3.5 |
| P | CRANK LENGTH (inch) | 6.5 | 6.7 | 6.7 | 6.9 |
| Q | WHEEL SIZE | 700C | 700C | 700C | 700C |
Note: In Store Pick Up Only
